Forged Dropouts







RE1020N. Angle 74°.
With Adjuster Hole


RE1070N. Angle 68°.
Hanger depth c. to c. 26mm.
With or Without Adjuster Hole


 		 RE1160N. Angle 62°. With Adjuster Hole





503 Dropout. Horizontal.
Long. 32mm Slot. ‘Allez’
With Adjuster Hole

506. Horizontal Dropouts.
65°. No Hanger.
No adjuster Holes


RE1185N. Angle 65°.




1187. Solid. 62°
1188. Solid. 69°
. 		JEPA. Solid, strong.

Rit.Forge.1. Ritchey Forged.
Single eye - 53,62,74°.
Extra strong.



Rit.Forge.O1. Ritchey Forged.
Single eye. Offset - 62°.
Available without eye in 53 or 62°.










RE1160. Angle 62°.
Hanger depth c. to c. 31mm.
With Adjuster Hole
 		 RE1200. Angle 59°.
Hanger depth c. to c. 29mm.
Strong double eye design.
No Adjuster Holes



RE1171. Angle 70°. but
profiled for wide angle acceptance.
Hanger depth c. to c. 31mm.
With Adjuster Holes
RE1260-2. Angle 68°.
Hanger depth c. to c. 28mm.
Profiled for wide angle acceptance.
With Adjuster Holes




RE1060. Angle 72°.
Hanger depth c. to c. 30mm.



RE508 Angle 71°.
Plug in Chain Stay 10.7mm. Forged Flat Seat Stay.
Offset. 29mm Hanger Depth
RE508 IX Stainless Version
10.2mm Chain Stay Plug. 26mm Hanger Depth.



FE1510N 9mm Slot



 		 FE1520N




 		 FE1530N




 		    FE1540
 With Safety Tabs



 		 RIT.FE
Ritchey Forged.






Plate Dropouts









RE1410N Track Ends. Angle 75°.
Campagnolo Pattern
RE1410S Above in Stainless Steel
RE1410F Stainless Steel Solder on Faces

RE1420 Track Ends
RE1410F Stainless Steel Solder on Faces


 		 RE1420N. Track Ends.
Bolt on Stainless Faces





Stainless Plate Dropouts












954 Vertical Plate Dropout.
No eyes. Stainless Steel.






 		 957 Vertical Plate Dropout.
Single Eye. Stainless Steel.





 		 955 Vertical Plate Dropout.
Double Eyelet. Stainless Steel.











953 Horizontal Plate Ends. Stainless Steel.
No Adjuster Hole

 		 956 Track Plate Ends. Stainless Steel


 		 958 No Eye.
959 Single Eye.





Sliding Dropouts












TSS1 Steel Plate Dropouts (Pair). Eyelet M6 Angle
TSS7 Stainless Steel Version available with Kick      Stand Mount. See here for Picture
Sliders attached with M8 Stainless Bolts Supplied
TSS2 Right Aluminium Slider (suitable for Rohloff)
 TSS8 Left Side Version


 		 TSS3 Left Aluminium Slider for Rohloff. Disc Mount




















TSS4 Left Aluminium Slider for Rohloff.                 TSS5 Left Aluminium Slider. With Disc Mount      TSS6 Right Aluminium Slider. With Gear Hanger
