LR12-1. Angle - 68 or 72°.
For 12.5mm. c/stay. 12.5mm s/stay. Please specify angle.

SLR12-1. Stainless Steel
For 12.5mm. c/stay. 12.5mm s/stay. Please specify 68 or 72°.
SLR12-132. For 13.2mm c/stays, 12.5mm s/stay 72° Stainless Steel
LR13M-1. ATB. 63°.
For 12.5mm. S/S 12.5mm. C/S Tip
Also 14mm. C/S Tip. Please specify.
SLR13M-1. Stainless Steel 14mm chain stay, 12.5mm seat stay


 		 LR09R-1. For Seat Stay Tip 10.5mm.
Chain Stay Tip 12.5mm. Angle: 72°.

SLR09R-1. As above - Stainless.

LR09V-1 For Seat Stay Tip 10.5mm.
Chain Stay Tip 13.0mm. Angle: 72°.

SLR09V-1. As above - Stainless



Ritchey Cast Ends.
54°.For 13.5mm. Chainstay,
12.5mm. Seat Stay Socket.

Also 74 degree (Chain Stay port 13mm/Seat Stay 12.0mm)

Also:
Ritchey Cast Ends Stainless
54, 62 or 74 degree as above



L4.  Llewellyn Rear Dropouts 72 degree.
 12.5mm seat stay and chain stay sockets.

L4S. As above in Stainless Steel. Also 64 degree
 		 Breezer Type Dropouts. For Tig Welding. Vari-angle

S-Breezer Type Dropouts - Stainless Steel

 		 953S Dropouts Stainless
14mm Chain Stay Plug, 12mm Seat Stay Plug.
57,  63 degree. Suitable for use with 953 Tubing

Also available in 70 degree, double eyelet only.






Dropouts. For Seat Stay 12.7mm, Chain Stay Port 12.7mm
Single M5 eyelet

DR07-64 Angle：64°, S-DR07-64 Stainless
DR07-68 Angle：68°, S-DR07-68 Stainless
DR07-72 Angle：72°





DR02. Dropouts. 66 degree. Double Eyelet.
Plug size is 11.5mm chainstay and 9.0mm seat stay.






C-111. Dropouts. Extra Strong. Suitable for Tandem.
Free Angle Seat Stay.
Socket for 13.5mm. Chainstay Tip.




BREEZER-H Breezer Style Steel. Replacable Steel Hanger
 		 DR10Z Steel Dropouts - Tig Type - 20mm width weld area. To be used with DR10A, B or C hangers. Come with bolts DR10A Alloy Hangers for DR10Z. Black Anodized.
DR10B Alloy Hangers for DR10Z. Black Anodized. DR10C Alloy Hangers for 142-12 Thru Axle. M12 x 1.5.
Can use Boost axle 148 length on a 142 hub . Black Anodized.
 		 1161 Horizontal Cast Dropouts. 71°
 Steel Only



DR04 Tig Dropouts. Disc brake Type
 		 DR03 Tig Dropouts. Post Mount Type and replaceable hanger. For 160mm rotor





DR06 Tig Dropout. Flat Mount Double Eye.
M12x1.5 Thru Axle




DR08Z  Steel Plates. Flanged for tig or fillet braze. Come with Bolts and Dropout Adjusters

Sliders Hangers can be ordered separately under the codes:
DR05H Right with hanger
DR05D Left with disc mount
DR05N Left with no disc mount




LR26A-1 Flat Mount Dropouts M12x1.5mm. Cromoly. Flange is 20mm across. Plug 14.4mm diameter. Axle hole centre to start of plug 88mm
S-LR26A-1. Stainless steel Version		 LR27A-2 Flat Mount Dropouts M12x1.5mm.
Flange is 20mm across.


LR31A-1 Thru Axle Dropouts. Aluminium Hanger M12x1.5mm. Flange is 20mm across





Track Type/Single Speed/Rear Facing


LR15 Track Ends 70 degree
10.85mm Seat Stay Plug.
11.5mm Chain Stay Plug.
SLR15 As above in Stainless


Y1 Track Ends 70 degree
10.85mm Seat Stay Plug
11mm Chain Stay Plug
With Threaded Adjuster Hole

Y1S As above. Polished Stainless
 		 DR2020 For Tig Weld. Vari angle








Y5 Cast Track Ends (Flat Type) 64 degree
Y5S Stainless Type		 Y1H Cast Dropouts. Double Eye 62 degree with Hanger. 10.85mm Seat Stay Plug
11mm Chain Stay Plug
With Threaded Adjuster Hole



Articulated Angle



LR10R.  For Seat stay dia. 10.5mm. Tip
For Chain stay dia. 12.5mm. Tip
S-LR10R-12.5. Stainless Steel but for 12.5mm Seat Stay Tip

 		 LR01. For Seat Stay Tip 12.5mm.
    For Chain Stay Tip 14mm.


R1 Dropouts. For Disc Brake
Chain stay Port 14mm. Seat Stay Port 12.5mm
Optional 14mm Seat Stay Socket. Please Specify if required.		  LR02 Dropout
Chain Stay Port 15.9mm Seat Stay Port 14mm
 Matches SCRR114V9 & SCRM114OV Chain Stays		 C1152. Dropouts.
8.9mm Seat Stay Plug
11mm Chain Stay Plug.



DR01 Dropouts. Horizontal
Chain stay Port 13mm. Seat Stay Port 11mm









Front Dropouts

LE09.
10.5mm plug * 12.7mm.
.		  LE20.
12mm Plug * 14.3mm.
 		  LE20-2
12mm Plug * 14.3mm.
S-LE20-2 Stainless steel version


903S - 10mm Plug Stainless Steel


Small Angle for Straight or Raked Forks



 C188B. 20.2mm. Plug. * 23.2mm


 		 C196B. 20.2mm. Plug. * 23.2mm




LE16-1 - 23mm plug * 25.4mm LE13-1 - 26.2mm plug * 28.6mm
S-LE13-1 As above in Stainless Steel		 FD01-1 . - 16.3mm Plus * 20.4mm




LE17H. Socket for 13mm tip.
SLE17H. As above in Stainless Steel
 		 953FN. Stainless Steel. 14.9mm Socket
 953FNN.   Non Stainless Version



S-LE302R Version in Stainless Steel		 LE21. Socket for 14mm Tip.
S-LE21 Stainless Steel Version
 		 DR20. Plug is 14.5mm diameter.
Plug fits Reynolds Disc Fork Blades. Less offset

S-DR20 Stainless Version. No Eyelet
905 . 13mm plug * 17.2mm with tabs 901. Socket for 13mm tip
901S. Stainless Steel Version
 		 L3S. Llewellyn Socket for 13.8mm tip. Stainless Steel


LE-MAX . For MAX Tear Drop Fully Profiled Fork blades.
 Non Standard.
 		 Art. 570. 10.7mm Plug * 13.25mm. Machined Steel.

 		 T1. For Straight or Raked Blades
Comes in 10.5mm or 11.5mm Plug. Please Specify
Machined Steel.
DR22 . 13.9mm Plug. Alternative to DR20 for Reynolds Disc fork blades. More offset. Slightly Loose Fit FD30 Front. Flanged. 31.8mm width M12x1.5
We can supply with Columbus 738TAN2 axle M12x1.5x100mm if requested.
FD31 Front. Flanged. 31.8mm width M15x1.5		 FD32 . Quick Release, Flanged 31.8mm width


FD26 . Thru Axle M12x1.5. 14mm Plug
FD27 . Thru Axle M12x1.5. 12mm Plug
We can supply with Columbus 738TAN2 axle M12x1.5x100mm if requested.
FD33. Thru Axle M15x1.5mm. 14mm Plug		             DR23. Thru Axle M12x1.5mm. 13.9mm plug. For flat mount includes extra flat mount boss. Left side is flattened for clearance.
We can supply with Columbus 738TAN2 axle M12x1.5x100mm if requested.		 DR24 . Quick Release. 13.9mm plug. For flat mount includes extra flat mount boss as per DR23. Left side is flattened for clearance.




Hanger Only


C132. Stainless Steel
Derailleur hanger.
